Enhanced Acoustic Sensitivity
Superb sensing element, digital signal processing algorithm with advanced filtering techniques allow device to detect the smallest particles.
red flame icon
Maximum Reliability
Rigorous self diagnostics, data averaging and use of filtering techniques provide fail to safe reliable operation.
red flame icon
Low Maintenance Cost
Minimum maintenance on site which makes it an easy choice for operator.
red flame icon
Non-intrusive Mounting
Connect Echo by supplied clamp to pipe or for subsea installation, place it in a funnel and you are ready to go.

Electrical Specifications

Power Requirements: +24VDC Nominal (+18 to 32VDC)

Power Consumption:  ≤ 2,4 W

Output From Echo: 4-20mA, industry standard analog output, Digital RS-485 Modbus RTU, Dry contact Relays, HART

Warm Up Time: 30 seconds

Mechanical Specifications

Material: 316 Stainless Steel or Aluminum

Conduit Connection: ¾” NPT

Dimensions: 5.75” x Ø 3.94” (146 mm x Ø 100 mm)

Mounting base size for pipes from m100 to 300 mm: 5.75” ( 138 mm)

Weight with mounting base: No more then 13.23lb (6 kg)

Operation Specifications

Method of Operation: Passive acoustic

Uncertainty Minimum: ± 3 % (with sand injection calibration)

Flow Velocity: ~  0.5 m/s

Particle Size: ≥ 10 μm – in gas; ≥ 20 μm – in oil

Data Storage: 90 days with a recording interval of 10 seconds

Operating Temperature: -60C to +85C ( -76F to 185F)

Pipeline Surface Temperature: -100C to +290C ( -148F to 554F)

Humidity Range: Up to 100%, non-condensing (Withstands up to 100% RH for short periods)

Storage/ Transportation Temperature: -50C to +50C ( -58F to 122F)

Ingress Protection: IP66 / IP 68

Lifetime/ Warranty: 10 years/ 2 years

Drilling and Production Platforms

Oil, gas and multiphase pipelines

Oil and gas wells
